PHD100

Post Hole Diggers

  • Dependable, rugged gearbox
  • Safety shielding covers auger and power take-off
  • Optional downforce kits
  • Optional hook-up stand


Maintenance Plans




Features



PHD0 Series Post Hole Digger gearbox PHD0 Series Post Hole Digger gearbox

The PHD0 Series Post Hole Digger has a rugged and dependable gearbox for a longer-lasting life.

PHD0 Series Post-Hole Digger safety shield PHD0 Series Post-Hole Digger safety shield

The PHD0 Series Post-Hole Diggers have a strong safety shield surrounding the auger and PTO to provide extra protection and longer life.

The downforce kits are for post hole diggers as identified below.

NOTE: The downforce kit requires hydraulic pressure from a tractor selective control valve (SCV) and a pressure-free return.

The auger position handle allows the operator to place the post-hole digger in the correct position before digging.



The field conversion auger position handle kit can be installed on PHD300 and PHD400 Series Post-Hole Diggers.

Great for mounting, dismounting, and storage Great for mounting, dismounting, and storage

The foldable hook-up stand allows operators to easily mount and dismount the post-hole digger from the tractor. The stand has several adjusting height options to accommodate the operator's needs.



The stand is ideal for storing the post-hole digger safely and prolongs the implement's life by keeping it off the ground.

Post-hole auger point Post-hole auger point

The Frontier™ PHA0 Series Post-hole augers come with a fishtail point.

Specifications


Compare the specifications of up to 4 models

Dimensions PHD100
Current Model
Boom ODPHD100: 7.3 cm
2.875 in.
PHD200: 8.9 cm
3.5 in.
PHD300: Reinforced: 8.9 cm
PHD400: Reinforced: 8.9 cm
Yoke ODPHD100: 6 cm
2.375 in.
PHD200: 7.9 cm
2.875 in.
PHD300: Reinforced: 7.9 cm
PHD400: Reinforced: 7.9 cm
Auger speed
Gearbox
Tractor compatibility
Gearbox hp ratingPHD100: 18.6 kW
25 hp
PHD200: 29.8 kW
40 hp
PHD300: 37.3 kW
50 hp
PHD400: 67.1 kW
90 hp
PTO hp rangePHD100: 13.4-18.6 kW
18-25 hp
PHD200: 13.4-29 kW
18-40 hp
PHD300: 13.4-37.3 kW
18-50 hp
PHD400: 29.8-61.7 kW
40-90 hp
3-Point hitch
Weight
UnitPHD100: 50.8 kW
112 lb
PHD200: 90.7 kW
200 lb
PHD300: 104.3 kg
230 lb
PHD400: 117.9 kg
260 lb
Shipping (2 per case)PHD100: 149.7 kg
330 lb
PHD200: 213.2 kg
470 lb
PHD300: 249.5 kg
550 lb
PHD400: 276.7 kg
610 lb
Auger
Model numberPHD100: PHA006, PHA009, PHA012
PHD200: PHA106, PHA109, PHA112
PHD300: PHA106, PHA109, PHA112, PHA118, PHA124, PHA132
PHD400: PHA106, PHA109, PHA112, PHA118, PHA124, PHA132
Auger diameterPHA130: 76.2 cm (30 in.)
PHA006: 15.2 cm (6 in.)
PHA009: 22.9 cm (9 in.)
PHA012: 30.5 cm (12 in.)
PHA106: 15.2 cm (6 in.)
PHA109: 22.9 cm (9 in.)
PHA112: 30.5 cm (12 in.)
PHA118: 45.7 cm (18 in.)
PHA124: 61 cm (24 in.)
Auger lengthPHA130: 111.8 cm (44 in.)
PHA006: 91.4 cm (36 in.)
PHA009: 91.4 cm (36 in.)
PHA012: 91.4 cm (36 in.)
PHA106: 121.9 cm (48 in.)
PHA109: 121.9 cm (48 in.)
PHA112: 121.9 cm (48 in.)
PHA118: 121.9 cm (48 in.)
PHA124: 121.9 cm (48 in.)
Auger weightPHA130: 96.6 kg (213 lb)
PHA006: 10.9 kg (24 lb)
PHA009: 19.1 kg (42 lb)
PHA012: 23.6 kg (52 lb)
PHA106: 14.5 kg (32 lb)
PHA109: 24.9 kg (55 lb)
PHA112: 34 kg (75 lb)
PHA118: 36.3 kg (80 lb)
PHA124: 47.6 kg (105 lb)
Auger flighting typePHA130: Double
PHA006: Single
PHA009: Double
PHA012: Double
PHA106: Single
PHA109: Double
PHA112: Double
PHA118: Double
PHA124: Double
Auger thicknessPHA130: 7.9 mm (0.3125 in.)
PHA006: 4.8 mm (0.1875 in.)
PHA009: 4.8 mm (0.1875 in.)
PHA012: 4.8 mm (0.18725in.)
PHA106: 4.8 mm (0.1875 in.)
PHA109: 4.8 mm (0.1875)
PHA112: 4.88 mm (0.1875 in.)
PHA118: 6.4 mm (0.25 in.)
PHA124: 6.4 mm (0.25 in.)
Auger Points
Auger dimensions
Cutting Edges
Set-up time
Warranty
